Ce Approved Chicken Feed Pellet Mill On Sale

KL series semi-covered E-motor feed pellet mill has the production capacity from 200kg/g to 800kg/h, but it is very light which can also be used in small poultry farm or used at home to make pellets. the principle of the small pellet mill is circular motion on a plate die with high qualified...

Send InquiryChat Now
Ce Approved Chicken Feed Pellet Mill On Sale

KL series semi-covered  E-motor feed pellet mill has the production capacity from 200kg/g to 800kg/h, but it is very light which can also be used in small poultry farm or used at home to make pellets. the principle of the small pellet mill is circular motion on a plate die with high qualified alloy steel roller through a special treatment, spindle and flat die by the action of the friction between the roll rotation and plate die, the material between the roller and template will go into gelatinization so protein coagulation changes, then pellets produced by the pellet mill discharges from the die hole and sent out by the rejection trays outside the machine, particle length can be adjusted through the incision on the small pellet mill.


Product description:

MKL series pellet machine is applied to the material with low adhesiveness and low shaping, such as the rice husk, sunflower seed husk, peanut shell and other fruit shell branch, trunk, bark and other wood waste, a variety of crop straws, cement, ash and other chemical materials.

Specifications of straw pellet machine:

ModelPowerCapacityPellet dia.N/G weightPacking sizeQty/20'/40'
MKL2257.5kw60-100kg/h4-10mm230/260kg90*47*98cm60/122  set
MKL22911kw100-150kg/h4-10mm300/350kg92*64*103cm54/112 set
MKL29515kw150-200kg/h4-10mm450/480kg108*52*105cm44/92 set
MKL33522kw200-300kg/h4-10mm560/600kg134*60*115cm28/58 set
MKL39530kw350-500kg/h4-10mm650/700kg152*60*121cm26/54 set

Pellets details:

Calorific value

  >4500~4800 kcal/kg

Density

  >1.1~1.3t/m3

Moisture

  <=10%

Combustion ratio

  >=98%

Heat efficiency

  >=81%

Discharged dust consistence

  <=80mg/m3

Ash content

  <=2%



Dry-processing, the production of feed pellet hardness and high, the surface is smooth, internal improvement, can improve digestion and absorption of nutrients.

Pellet produced in one process, without over size and recycling , pelletizing rate larger than 90%. Wide flexibility for various feed stocks.


Nice looking in shape, simple in structure, easy in operation
